Product Code: H-28/VCV

Features
• 1/2” (15 mm) to 2” (50 mm) sizes
• Vertical Type Check Valve
• Threads as per BSPT
• Brass seat
• Nitrile rubber washer
• Powder coated long life paint
• Available in Cast Iron

Bill of Material and Suitability

S.No.	Component	Material
1	Upper Body	Cast Iron
2	Nut/Bolt	M.S.
3	Gasket
4	Rubber
5	Valve Seat	Brass
6	Lower Body	Cast Iron
7	Valve	Cast Iron

Pressure Testing
Test Pressure		Max C.W.P
Body		Seat		Body / Seat
300 PSI	21 kg/cm²	150 PSI	11 kg/cm²	150 PSI	11 kg/cm²
# Hydraulically

Suitability : Water, Oil

Dimensions

DN SIZE		Dimensions
Inches	mm	A*	B*
1/2	15	70	80
3/4	20	79	100
1	25	94	125
1-1/4	32	98	126
1-1/2	40	111	132
*Approx. dimensions in mm

Applications

Plumbing (Hot & Cold Water), Construction Industry, Water & Effluent Treatment Plants, Solvent Plants, Distribution of Oils and for numerous other applications.
